Save $10
TP-Link
SKU: SWTL-SG105MPE
Model Number: TL-SG105MPE
Price:
$89 $99
Stock:
Sold out

Cannington

Pickup currently unavailable

2/4 Nicholson Road
Beckenham WA 6107
Australia

+61892020104

Osborne Park

Pickup currently unavailable

3/52 Frobisher Street
Osborne Park WA 6017
Australia

+61892020100

Rockingham

Pickup currently unavailable

3/31 Council Ave
Rockingham WA 6168
Australia

+61892020118

Description

TP-Link TL-SG105MPE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+

  • Five 10/100/1000Mbps RJ45 ports
  • Equipped with four 802.3af/at PoE+ ports with up to 30W for each port, data, and power can be transferred on one single cable
  • Supports PoE power up to 120 W for all PoE ports*
  • Provides network monitoring, traffic prioritization, VLAN features, and PoE Auto Recovery
  • Simple network set-up on top of plug-and-play connectivity
  • Web-based user interface and Easy Smart Configuration Utility simplify configuration
  • Fanless design lowers energy consumption and eliminates operating noise.

Specifications:

HARDWARE FEATURES
Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at
Interface Five 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Power Supply External Power Adapter (Output: 53.5 VDC / 2.43 A)
PoE Ports (RJ45) Standard: 802.3 af/at compliant
PoE Ports: Port 1- Port 4
PoE Power Budget: 120 W
Dimensions ( W x D x H ) 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm)
Max Power Consumption 4.34 W (220 V/50 Hz with no PD connected)
137.01 W (110 V/50 Hz with 120 W PD connected)
Max Heat Dissipation 14.8 BTU/h (with no PD connected)
467.17 BTU/h (with 120 W PD connected)
PERFORMANCE
Switching Capacity 10 Gbps
Packet Forwarding Rate 7.44 Mpps
MAC Address Table 2 K
Packet Buffer Memory 1 Mb
Jumbo Frame 16 KB
SOFTWARE FEATURES
Quality of Service Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
L2 Features IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
PoE Auto Recovery
Extend Mode
VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
Management Web-based GUI
Easy Smart Configuration Utility
Transmission Method Store-And-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SG105MPE
Power Adapter
Installation Guide
Rubber Feet
System Requirements Microsoft® Windows® for running Utility
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~95%RH non-condensing


Features:

Multiple Application Scenarios

The TL-SG105MPE is fully compatible with PoE devices, such as IP cameras, access points, and IP phones. It also works
with non-PoE wired devices, such as PCs, printers, and IPTV.

  • Surveillance

    Works with IP Cameras

  • Conference Call

    Works with IP Phones

  • Wi-Fi Coverage

    Works with Omada EAPs

  • Wired Connections

    Works with PCs and Printers

Dedicated 4 PoE+ Ports (120 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 120 W PoE power budget* for the 4× gigabit PoE+ ports makes it has wide range of applications, such as surveillance, offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and etc.

Easy to Use

1. Plug In

2. Connect Devices

3. Enjoy

Value-Added Features Bring Unexpected Experiences

  • QoS for a Lag-Free Experience

    Ensures smooth traffic for latency sensitive applications, such as voice and video.

  • IGMP Snooping for Multicast Optimization

    Ensures a better network experience, especially for applications like IPTV, by optimizing multimedia traffic delivery.

  • VLAN for Security

    Helps to create network with higher security and better overall performance by dividing network into smaller groups

Making Management Easy

TL-SG105MPE offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG105MPE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.

Multiple Factors Guarantee Stable Operation

           System Self-Healing with PoE Auto Recovery

           The switch automatically detects and reboots the PD devices, such as cameras                 and APs, when they fall offline or go unresponsive, guaranteeing the stable                       operation of PoE-connected devices, without need for manual monitoring and                 restart.

  • Supports PoE Power up to 30 W for each PoE port

    Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. It is fully compatible with more 802.3at PD devices.

    Great Compatibility with PD Detection



    • Automatically detects the required PoE power for your device and protects your non-PoE equipment from being damaged.



Long Product Life with Durable Metal Casing

Interior components of TL-SG105MPE are protected by high-quality metal casing to ensure a product longevity. Having passed an array of stringent reliability tests, TL-SG105MPE delivers switching performance you can depend on.
