Description
The CyberPower PFC Sinewave Series offers users from home to SMEs clean and stable battery backup while the featured RJ11/RJ45 port ensures phone, fax, and modem lines are protected from surges. With Automatic Voltage Regulation (AVR) stabilizes the AC signal and maintains a safe voltage, this allows the UPS to maintain safe power levels for the connected equipment without resorting to battery power. The multifunction LCD readout provides immediate access to precise information of critical power/battery condition.
The included PowerPanel® Personal Edition management software showcases the featured rich abilities such as input/output power voltage readings, self-diagnostics, scheduled-shutdown, and approximate battery backup time. With the Energy-Saving Technology, the PFC Sinewave Series can save up to 75% of electricity therefore save your electricity expenses.
Features & Benefits:
- Pure Sinewave output
- GreenPower UPS™ Technology
- Automatic Voltage Regulator
- EMI, RFI, Surge & Spike Protection
- Phone, Fax, Modem, DSL, and Network Protection
- Auto-Restart/Auto-Charge
- LCD Status Monitor
- USB Connectivity Port
- User-Replaceable Batteries
- PowerPanel® Personal Edition Software
- Equipment Protection Policy up to 25,000 AUD
Specifications:
- Phase: Single Phase
- Form Factor: Tower
- UPS Topology: Line-interactive
- Energy Saving Technology: GreenPower UPS Bypass Technology
- Nominal Input Voltage ( Vac ): 230
- Input Voltage Range ( Vac ): 170 - 270
- Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
- Input Frequency Detection: Auto-sensing
- Rated Input Current ( A ): 10
- Input Connector Type: IEC C14
- Power Cord Length (m.): 1.83
- Output Capacity (Watts): 780
- On Battery Waveform: Pure Sine Wave
- On Battery Voltage(s) ( Vac ): 230 ± 10%
- On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
- Automatic Voltage Regulation (AVR): Single Boost
- Overload Protection: Internal Current Limiting, Circuit Breaker
- Outlet(s) - Total: 6
- Outlet(s) - Battery & Surge Protected: 6
- Typical Transfer Time ( ms ): 4
- USB Charging Port(s): USB-A x 2
- USB Charging Current: 5 V/ 2.1 A
- Runtime at Half Load ( min ): 9
- Runtime at Full Load ( min ): 2.5
- Typical Recharge Time ( Hours ): 8
- Battery Type: Sealed Lead-acid
- Battery Cartridge: RBP0124
- RBP Quantity ( pcs ): 1
- Surge Suppression ( Joules ): 405
- EMI/RFI Filtration: Yes
- Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
- LCD Panel: Yes
- LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
- LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Event & Log
- HID Compliant USB Port(s): 1
- Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
- Management Cable ( pcs ): Power Cord x2, USB Cable x1
- Ethernet Data Transmission Speed: Up to 1Gbps
- Power Management Software: PowerPanel Personal (Recommended)
- Enclosure Construction: Plastic
- Dimensions: 100 x 265 x 370mm
- Weight: 10.4kg
- Certifications: CE, EAC, RCM
