Description
COOLER MASTER MASTERBOX E500 + ELITE 500W 230V PSU, ATX, LARGE FILTERED INTAKES, SUPPORT O
-
Large Filtered Intakes
-
With 500W PSU
-
Versatile Cooling Options
-
Full Black Coating & PSU Cover
-
Breathable Power Supply Shroud
-
Room For Upgrades
-
Removable HDD Cage
STEADFAST
The Elite 500 is the essential solution for optimised cooling. Substantial ventilation on the front panel allows fresh air into the system for both air-cooled and liquid cooled configurations.
For simple tasks, the Elite 500 is a cost-effective solution to professional computing. For higher-demand tasks, the Elite 500 boasts a high compatibility for upgrades, able to house liquid cooling and provides clearance for the longest, widest graphics cards.
LARGE FILTERED INTAKES
The front panel is constructed with a substantially large, unrestricted intake grill to provide superb airflow to the system.
VERSATILE COOLING OPTIONS
Support for up to six fans and front, top, and rear radiator support ensure that performance is not compromised.
WITH ODD SUPPORT
The ODD version of the Elite 500 is slightly deeper in comparison to its non-ODD counterpart.
FULL BLACK COATING & PSU COVER
Let your system stand out with an all-black background and a PSU cover to hide cables.
BREATHABLE POWER SUPPLY SHROUD
The PSU cover is ventilated on top of the power supply location, this allows actively cooled units to be installed either with the fan facing the top or bottom, also with the possibility of installing passively cooled power supplies. The Elite 500 comes preinstalled with a 500W power supply.
STEEL LEFT SIDE PANEL
The ELITE 500 ODD Features a steel side panel for those who prefer a stealthy minimalist look.
ROOM FOR UPGRADES
Support for up to a 400mm graphics card in the ODD version, a 161mm CPU cooler, and multiple fans/radiators locations provides room for upgrades to stay ahead of the game.
HEADSET JACK
The single 4 pole headset jack features both Audio and Microphone capabilities simultaneously so that separate jacks are not needed.
VERSATILE HDD CAGE
The HDD cage is (re)movable. The cage can be shifted forward to make room for a longer PSU, backwards for additional radiator space, or completely removed if HDD storage is not needed.
AMPLE STORAGE SUPPORT
Elite 500 comes with support for up to 2x 3.5" and up to 5x 2.5" drives.
Storage can be mounted behind the motherboard tray and withing the versatile HDD cage
100% TOOL-LESS MOUNTING
The case implements Cooler Master's exclusive tool-less storage mounting system. Easy, fast and secure mounting guaranteed without the need for any screws.
SPECIFICATIONS
Elite Series
Mid Tower
E500-KN5N50-S00 (Steel, ODD + 500W Power Supply)
Black
Steel, Plastic
464 x 204 x 455mm (incl Protrusions, ODD)
457 x 204 x 455mm (excl. Protrusions, ODD)
42.40L (exlc. Protrusions)
Mini ITX, Micro ATX, ATX
7
N/A
1
2
5
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
1x 120mm
2x 120mm, 2x 140mm
2x 120mm, 3x 120mm (remove ODD bracket)
1x 120mm
120 / 240mm (32mm max motherboard component height)
120mm, 140mm, 240mm, 280mm, 360mm (Remove ODD)
120mm
Steel: 163mm
180mm
400mm (w/o front fans & radiator)
18.5mm
Front, Top, Bottom
Bottom Mount, ATX - 500W Included
2 Years
