Description
🔧 Key Specifications
Socket: AMD AM5, supporting Ryzenâ„¢ 7000, 8000, and 9000 Series processors
Chipset: AMD X870E
Memory: 4× DDR5 DIMM slots, up to 256GB, with overclocking support beyond 8200 MT/s
Expansion Slots: 2× PCIe 5.0 x16 slots (x16 or x8/x8)
Storage:
3× M.2 PCIe 5.0 x4 slots
2× M.2 PCIe 4.0 x4 slots via ROG DIMM.2 module
4× SATA 6Gb/s ports
USB Ports:
Rear: 2× USB4 Type-C (40Gbps), 10× USB 3.2 Gen 2 (10Gbps)
Front: 1× USB 3.2 Gen 2x2 Type-C (20Gbps, up to 60W PD/QC4+), 1× USB 3.2 Gen 2 Type-C (10Gbps)
Networking:
Marvell AQtion 10Gb Ethernet
Realtek 5Gb Ethernet
Wi-Fi 7 (802.11be)
Bluetooth 5.4
Audio: ROG SupremeFX 7.1 Surround Sound with ALC4082 codec and ESS ES9219 DAC
Form Factor: E-ATX
🌟 Standout Features
Power Delivery: Robust 20+2+2 power stages (110A) with dual ProCool II connectors, ensuring stable power for high-performance CPUs
Cooling: Comprehensive thermal design with large VRM heatsinks, L-shaped heat pipe, and multiple fan headers, including support for water pumps
AI Enhancements:
AI Overclocking: Automatically tunes CPU performance
AI Cooling II: Dynamically adjusts fan speeds for optimal cooling
AI Networking II: Optimizes network settings for low-latency gaming
AI Cache Boost: Enhances cache efficiency for AI workloads, improving performance by up to 12.75%
User-Friendly Design: Features like Q-Release for easy GPU removal, M.2 Q-Latch for tool-free SSD installation, and a customizable 5-inch LCD display for system monitoring
