The ALOGIC USB-C Dock PLUS is the next generation USB-C peripheral designed to work with the latest USB-C and Thunderbolt 3 enabled computers. Featuring ALOGIC’s latest advancement in the R&D of USB-C technology, this next generation dock PLUS is one of the most advanced products in its class across the industry.
Truly Universal: Connect all you want
The dock PLUS features a full array of ports ranging from 1 x HDMI with support for 4K@30Hz, 1 x Mini DisplayPort with support for 4k@30Hz, 1 x Gigabit Ethernet for wired ethernet, 2 x USB 3.0 (USB-A) ports for your standard USB accessories, 1 x Micro SD and SD Card Readers and 1 x USB-C port with support for up to 100W of Power Delivery for charging you laptop when connected to a suitable USB-C Charger. The USB-C port and Data transmission from the same port. The USB-C port also supports Data transmission from the same port along with power.
Single 4K or Dual 1080p Monitors:
The Dock PLUS supports either a single monitor with up to 4K resolution when one of the HDMI or It can also support two monitors with up to 1080p FULL HD resolution simultaneously when the HDMI and Mini DisplayPort outputs are used together.
An active Mini DisplayPort cable/adapter must be used when the connection from the Mini DisplayPort output on the dock is being converted to a HDMI/DVI/VGA connection.
The Dual monitor support is only compatible with Windows 10 and above computers. Only single monitor is supported on Mac computers.
Eliminate Magnetic Interference:
The dock features comprehensive shielding to eliminate all magnetic interference caused by Bluetooth, Wi-fi or any other frequencies. This help improves the performance of your laptop and tablet across different locations and environments.
Power Delivery 3.0 Technology: Data + Power
The Docking station uses the latest Power Delivery (PD 3.0) specification, that lets you charge your MacBook or other USB-C enabled laptop with up to 100W of power. The USB-C port in this next generation dock also supports data transmission for connecting a USB-C storage device, peripheral, smart phone etc for transferring data.
PRODUCT SPECIFICATION
User Interface
Input: USB-C x 1
Output: HDMI 4K@30Hz x 1, Mini DisplayPort x 1, Gigabit Ethernet x 1, USB-A (USB 3.1 Gen1) x 2, USB-C (Power Delivery & Data) x 1 (Up to 100W & USB 3.1 Gen 1 Speed), Micro SD & SD Card Reader x 1
Power
Supports up to 100W Power Delivery via USB-C Port
Data Rate:
Supports USB 3.1 Gen 1 Data Rate from USB-C and USB-A Ports
Resolution:
HDMI Port supports 4K@30Hz
Mini DisplayPort supports 4K@30Hz
Physical Characteristics
Product Dimension: 117 x 46.87 x 15 mm
Colour: Space Grey
Weight: 138g
Materials: Aluminium & ABS
Package Content:
1 x User Manual
1 x USB-C Ultra Dock PLUS
PRODUCT FEATURE
* Compact and light weight design
* Aluminium & ABS construction for the most elegant look
* Full array of ports – HDMI 4K@30Hz, Mini DisplayPort 4k@30Hz, Gigabit Ethernet, USB-C (Data & PD 100W), USB-A & Micro/SD Card Readers.
* Supports charging your Macbook with up to 100W power when connected with a suitable charger
* Supports single monitor resolution with up to 4k@30Hz via the HDMI port and Mini DisplayPort.
* Supports two monitors with up 1080p FULL HD resolution simultaneously when the HDMI and Mini DisplayPort outputs are used together on windows computers.
* Two port USB-A hub for connecting keyboard, mice, printer or another existing USB-A peripheral.
* Supports both Micro & SD memory cards
* Warranty – 1 Year
|
|
|
|
