| Main Specifications |
| Device Type |
Server processor |
| Processor Number |
E-2324G |
| Clock Speed |
3.10GHz |
| Max Turbo Speed |
4.60 GHz |
| Multi-Core Technology |
4-core |
| Number of Threads |
4 threads |
| Bus Speed |
8 GT/s |
| Manufacturing Process |
14 nm |
| Product Collection |
Intel Xeon E Processor |
| Code Name |
Products formerly Rocket Lake |
| Vertical Segment |
Server |
| Processor |
| Cache |
8 MB Intel® Smart Cache |
| Thermal |
| Desigh Power |
65W |
| Memory Specifications |
| Max Memory Size (dependent on memory type) |
128 GB |
| Memory Types |
DDR4-3200 |
| Max # of Memory Channels |
2 |
| ECC Memory Supported |
Yes |
| Intel Optane Persistent Memory Supported |
No |
| Integrated Graphics |
| Type |
Intel UHD Graphics P750 |
| Base Frequency |
350 MHz |
| Max Dynamic Frequency |
1.3 GHz |
| Max Supported Memory Size |
64 GB |
| Max Supported Resolution |
Max Resolution (HDMI) 4096 x 2160 @60 Hz, Max Resolution (DP) 5120 x 3200 @ 60 Hz, Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 @ 60 Hz |
| Features IG |
Intel Quick Sync Video, Intel InTru 3D Technology, Intel Clear Video HD Technology, Intel Clear Video Technology |
| Expansion Options |
| Scalability |
1S |
| PCI Express Revision |
4.0 |
| PCI Express Configurations |
Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 |
| Max # of PCI Express Lanes |
20 |
| Package Specifications |
| Sockets Supported |
FCLGA1200 |
| Max CPU Configuration |
1 |
| Case Temperature |
100°C |
| Package Size |
37.5mm x 37.5mm |
| Miscellaneous |
| Package Type |
OEM, Tray |
| Use Conditions |
Server/Enterprise |
